Logarithmic Periodic Broadband Antennas |
UHALP 9108 A |
Log.-Periodic Antenna, alum. Tubing, 250 – 2400 MHz, low loss, 1 kW power |
VUSLP 9111-1000 |
Log.-Per. Antenna, aluminium tubing, 1000 – 3000 (4000) MHz, low loss, 1 kW. |
VUSLP 9111-400 |
Log.-Periodic Antenna, alum. Tubing, 400 - 3000 (4000) MHz, low loss, 1 kW. |
VUSLP 9111 |
Log.-Periodic Antenna, alum. Tubing, 200 – 2300 (4000) MHz, low loss, 1 kW power |
VUSLP 9111 B |
Log.-Periodic Antenna, alum. Tubing, (180) 200 - 3000 (4000) MHz, low loss, 1 kW power |
VUSLP 9111 E |
Log.-Per. Antenna, aluminium tubing, 1 kW power, 70 (65)-3000 (4000) MHz. Recommended adapter: KG 9201. EN 61000-4-3 |
VUSLP 9111 F |
Log.-Per. Antenna, aluminium tubing, dismountable, (75) 80 MHz - 3 (4) GHz. Recommended adapter: KG 9201. |
CCA 9111 F |
Case for VUSLP 9111 F. 4 elements must be unscrewed and the fastlinks must be removed. All parts then fit in this aluminum case 83.5x73x20cm. Assembly time: less than 5 Minutes. Suitable Torx screw driver in the case. |
VULP 9118 A |
Log.-Per. Antenna, aluminium tubing, 1 kW power, 180 -1500 (2000) MHz |
VULP 9118 B |
Log.-Per. Antenna, aluminium tubing, 1 kW power, 160-1500 (2000) MHz |
VULP 9118 C |
Log.-Per. Antenna, aluminium tubing, 1 kW power, 100-1400 (2000) MHz |
VULP 9118 C spe- cial |
Log.-Per. Antenna, aluminium tubing, 1 kW power, 100-1400 (2000) MHz. Nearly identical gain as VULP 9118 C but with reduced width. Special=folded longest elements. |
VULP 9118 D |
Log.-Per. Antenna, aluminium tubing, 1 kW power, (80) 95 -1500 (1800) MHz |
VULP 9118 D spe- cial |
Log.-Per. Antenna, aluminium tubing, 1 kW power, (80) 95 -1500 (1800) MHz. Nearly identical gain as VULP 9118 D but with reduced width. Special = folded longest elements. |
VULP 9118 D HP |
Log.-Per. Antenna, aluminium tubing, high power with 7/16.-connector, (80) 95 -1500 (1800) MHz |
VULP 9118 D HP sp |
Log.-Per. Antenna, aluminium tubing, high power with 7/16.-connector, (80) 95 -1500 (1800) MHz, nearly identical gain as VULP 9118 E High Power but with reduced width. Special = folded longest elements. |
VULP 9118 E |
Log.-Per. Antenna, aluminium tubing, 1 kW power, 75 (50)-1500 MHz. |
VULP 9118 E special |
Log.-Per. Antenna, aluminium tubing, 1 kW power, 75 (50)-1500 MHz. Nearly identical gain as VULP 9118 E but with reduced width. Special=folded longest elements. |
VULP 9118 E High Power |
Log.-Per. Antenna, aluminium tubing, high power, 7/16-connector, 75 (50)-1500 MHz. |
VULP 9118 E HP sp |
Log.-Per. Antenna, aluminium tubing, high power, 7/16-connector, 75 (50)-1500 MHz. Nearly identical gain as VULP 9118 E HP but with reduced width. Special=folded longest elements. |
VULP 9118 F |
Log.-Per. Antenna, al. tubing, end discs, 1 kW power, 55 -1800 MHz |
VULP 9118 G |
Log.-Per. Antenna, al. tubing, end discs, 1 kW power, 45 -1500 MHz |
VULP 9118 G spe- cial |
Log.-Per. Antenna, al. tubing, end discs, 1 kW power, 45 -1500 MHz. Nearly identical gain as VULP 9118 G but with reduced width. Special=folded longest elements. |
VULP 9118 H |
Log.-Per. Antenna, aluminium tubing, 1 kW power, (26) 30 - 1500 (1800) MHz, N-connector gain 6 dBi, VSWR<3, width 5.2 m, length 4.8 m, weight 35 kg. |
Opt. WP 9118 H |
Option: grey coating and sealing for outdoor use |
USLP 9142 |
UHF – SHF Log. – Per. Antenna, 0.7 – 5 (8) GHz |
USLP 9143 |
UHF – SHF Log. – Per. Antenna, (0.25) 0.3 – 7 (8) GHz |
USLP 9143 B |
UHF – SHF Log. – Per. Antenna, (0.18) 0.2 – 7 (8) GHz |
ESLP 9145 |
UHF – EHF Log. – Per. Antenna, (0.7) 1- 18 (20) GHz, N-connector |
XSLP 9142 |
Dual Polarized UHF-SHF Log.-Per. Antenna, 800 MHz – 3(5) GHz, 50 W |
XSLP 9143 |
Dual Polarized UHF-SHF Log.-Per. Antenna, 300 MHz – 3(5.5) GHz, 50 W |
|
Stacked Logarithmic Periodic Broadband Antennas |
STLP 9128 C- N |
Stacked double Log.-Per. Antenna, typ. gain: 9 dBi, alum. Tubing, high power, (150) 200 - 1500 (4000) MHz, N-connector max. power 1 kW for lower frequency range or limited by N-connector for higher frequency range. |
STLP 9128 C- 7/16 |
Stacked double Log.-Per. Antenna, typ. gain: 9 dBi, alum. Tubing, high power, (150) 200 - 1500 (4000) MHz, 7/16-connector max. power 2 kW for lower fre- quency range or limited by 7/16-connector for higher frequency range. |
Opt. 13-30 |
Option: with 13-30-connector limited to 2500 MHz but higher power up to 8 kW including adapter similar to AA 9202 |
STLP 9128 D- N |
Stacked double Log.-Per. Antenna, typ. gain: 9 dBi, alum. Tubing, high power, 80 -3000 (4000) MHz, max. power 1 kW in the lower frequency range, power limited by N-connector in the higher frequency range, fastlinks for quick removal of the rear parts of the antenna. Recommended Adapter: AA 9209 |
STLP 9128 D- 7/16 |
Stacked double Log.-Per. Antenna, typ. gain: 9 dBi, alum. Tubing, high power, 80 -3000 (4000) MHz, max. power 2 kW in the lower frequency range, power limited by 7/16-connector in the higher frequency range, fastlinks for quick re- moval of the rear parts of the antenna. Recommended Adapter: AA 9209 |
STLP 9128 D sp-N |
Like STLP 9128 D but with folded longest elements and smaller structure angle, N-connector, fastlinks for quick removal of the rear parts of the antenna. Anten- na diameter < 150 cm. Recommended Adapter: AA 9209. |
STLP 9128 D sp-7/16 |
Like STLP 9128 D but with folded longest elements and smaller structure angle, 7/16-connector, fastlinks for quick removal of the rear parts of the antenna. An- tenna diameter < 150 cm. Recommended Adapter: AA 9209. |
STLP 9128 E- N |
Stacked double Log.-Per. Antenna, typ. gain: 9 dBi, alum. Tubing, high power, (65) 80 -1500 (3000) MHz, N-connector, max power in the lower frequency range 1 kW, in the upper frequency range limited by N-connector, fastlinks for quick removal of the rear parts of the antenna. Recommended Adapter: AA 9209 |
STLP 9128 E- 7/16 |
Stacked double Log.-Per. Antenna, typ. gain: 9 dBi, alum. Tubing, high power, (65) 80 -1500 (3000) MHz, 7/16-connector, max power in the lower frequency range 2 kW, in the upper frequency range limited by 7/16-connector, fastlinks for quick removal of the rear parts of the antenna. Recommended Adapter: AA 9209 |
STLP 9128 E sp-N |
Like STLP 9128 E but with folded longest elements and smaller structure angle. N-connector, antenna diameter < 150 cm. Fastlinks for quick removal of the rear parts of the antenna. Recommended Adapter: AA 9209 |
STLP 9128 E sp-7/16 |
Like STLP 9128 E but with folded longest elements and smaller structure angle. 7/16-connector, antenna diameter < 150 cm. Fastlinks for quick removal of the rear parts of the antenna. Recommended Adapter: AA 9209 |
STLP 9129 |
Stacked double Log.-Per. Antenna, typ. gain: 9 dBi, alum. Tubing, (70) 80 -9000 (10500) MHz, N-connector, fastlinks for quick removal of the rear parts of the antenna, tip with radome. Recommended Adapter: AA 9209. Ideal for IEC 61000-4-3. |
STLP 9129 7/16 |
Stacked double Log.-Per. Antenna, typ. gain: 9 dBi, alum. tubing, (70) 80 - 7500 MHz, 7/16-connector, fastlinks for quick removal of the rear parts of the antenna, tip with radome. Recommended Adapter: AA 9209. Ideal for IEC 61000-4-3. Max. power: 1400W @ 500 MHz, 950 W @ 1000 MHz, 380 W @ 5000 MHz Frequency range limited by large connector to ca. 7.5 GHz |
STLP 9148 |
Stacked double Log.-Per. Antenna, typ. gain: 9 dBi (0.7) 1 – 18 (20) GHz, N-connector |
STLP 9149 |
Stacked double Log.-Per. Antenna for IEC 61000-4-3 typ. gain 10.3 dBi, (0,6) 0,7 – 9 (10,5) GHz, N-connector female. |
|
Biconic Logarithmic Periodic Antennas (Hybrid) |
VULB 9161 SE |
TRILOG Super Broadband test Antenna, 30 – 1000 (2000) MHz, 1 kW with short Triangle elements, diameter < 150 cm |
VULB 9162 |
TRILOG Broadband Antenna 30 MHz - 7 GHz, 100 W, diameter < 150 cm |
VULB 9163 |
TRILOG Super Broadband test Antenna, (25) 30 – 3000 (4000) MHz, 100 W (200 W) |
VULB 9168 |
TRILOG Super Broadb. Test Antenna, (25) 30-1000 (2000) MHz, 10 W, reduced width, diameter < 1.5 m. |
